ER 70S-6 x 11 lb Spool

Description

Inweld 70S-6 contains higher levels of manganese and silicon than many other classifications of mild steel wires. The increased Mn and Si content gives stronger deoxidizing power when welding over mild or carbon steel that may have traces of rust or mill scale such as found on structural and plate steels. Inweld 70S-6 is used for single or multi-pass welding.

An excellent choice for sheet metal applications, where the higher silicon content creates excellent “wetting out” properties and produces weld deposits that are essentially flat to slightly convex and require little or no grinding. Weld deposits are x-ray quality.

Features

• Welding Method: MIG
• AWS Specification: AWS A5.18
• Tensile Strength (psi): 70000
• Yield Strength (psi): 58000
• Elongation (%): 22
• Specific Alloy: 70S-6
• AWS Description: ER 70S-6
• Size (diameter, in.): 0.035
• Weight (lbs): 11
