Description

Keep Water, Oil, And Dirt Out of Your Compressed Air

• Less corrosion of pipes and tools means less downtime
• Avoid splotches & stains on your projects with proper filtration

Energy Efficient Aluminum Refrigerated Air Cooling System

• Designed for maximum performance and efficiency

Rust Free, Stainless Steel Heat Exchanger

• Maximum heat transfer, maximum dryer life & less maintenance

Refrigerated Air Inlet Inner Cooler

• Provides trouble free operation for high temp cooling

Environmentally Safe

• Uses 134A refrigerant to prevent damage to the ozone layer

Compact And Efficient

• Great for a 10HP systems
• 58 CFM

Easy To Install

• Uses 120V single-phase power, no special wiring needed

Added Features

• Auto Drain System
• Refrigerant Pressure Gauge
• Outlet Air Baffle Heater

Features & Benefits

Purifies compressed air by chilling to condense moisture
Condensate is drained carrying oil & dirt partials away from the air
Auto drain system – eliminates the need for daily maintenance
The refrigerant pressure – gauge clearly monitors the performance of dew point temp (models under 400 CFM)
PLC Display (models 400 CFM & above)
Outlet air baffle heater –  prevents condensation on outlet air piping
Heavy-duty steel cabinet
Trouble-free operation refrigerated air inlet inner cooler for high temp cooling
Top-mounted condenser & fan motor
Environmentally friendly 134A refrigerant

Our EMAX air dryer is the only energy-efficient system with an aluminum refrigerated air inner cooler. The air is filtered of all solid particles 0.01 micron and larger.  Clean, dry compressed air leaving the dryer minimizes maintenance and repair and also reduces internal dryer contamination. We designed them with a Non-corrosive inner and aftercooler. Our dryers feature stainless steel heat exchangers for maximum dryer life and less maintenance.  Emax Air dryers are UL-CSA-approved scroll compressors & electric systems for high efficiency and durability. They feature adjustable hot bypass for complete dryer function in low and high CFM flow preventing dryer freeze-up.

5-year Warranty on the Heat Exchanger
2 year warranty on the unit
