Description And Application

Inweld A-3 is a 5% silicon aluminum arc welding electrode with exclusive self-lifting slag. For arc welding aluminum alloyed with copper, silicon, and magnesium. Also excellent for joining dissimilar grades of aluminum. Start by using the upper portion of the amperage range. Feed the electrode quickly and move fast maintaining a very close arc gap.

Typical Weld Metal Properties

                                     AWS Spec

• Tensile Strength:  34,000 psi
• Yield Strength:    20,000 psi
• Elongation:             18%

 Recommended Parameters

 SMAW

• 5/64”                          20-60
• 3/32”                          50-80
• 1/8”                            70-120
• 5/32”                          110-150

Features

• Specific Alloy: A-3
• Welding Method: Stick
• Tensile Strength (psi): 34000
• Yield Strength (psi): 20000
• Elongation (%): 18
• Weight (lbs): 5
• Size (diameter, in.): 3/16
